Note:
Autel MaxiBAS BT608E has no IP restrictions, used globally.Autel BT608 and BT608 (E) are the SAME products, E in its name means Sold Online.
Autel MaxiBAS BT608E
Autel Battery Tester MaxiBAS BT608 (E) offers the technician everything required to service a vehicle’s starting and charging system including SoC and State of Health (SoH) battery testing and vehicle-specific battery replacement instructions and battery registration. The tool also enables Starter and Alternator testing, and the optional Amp Clamp and Multimeter enable even more thorough electrical systems diagnostics.
Features:
Support in-vehicle and out-of-vehicle test of all vehicle batteries
Test 6- and 12-volt batteries: 100 - 3000 CCA, Test 12- and 24-volt cranking/charging systems
Test Flooded, AGM, AGM Spiral, EFB and GEL batteries
Compatible with CCA, CA, SAE, EN, IEC, DIN, JIS and MCA protocols
Quick display of battery specifications through battery barcode scan
The First Car Battery Tester with All Systems Diagnostics
Illustrate instruction guides for battery positioning and testing & reseting
Detailed Battery Replacement Instruction, One-Touch Battery Registration for 53 vehicle makes
Electrical Systems Health Check & Reset
Lithium Vehicle Battery Test for 13 Makes: check the health of Lithium battery for Temperature, Tolerance etc.
Battery Usage history (BMW only): display SOC (State of Charge) in the last 5 days, Proportion of SOC duration, Estimated current mileage comparison (battery replacement).
Multimeter Compatible & 13+ Language Options
Esay Data Review, Share, Print
Innovative Adaptive Conductance Technology:
Unlike traditional battery testers, Autel MaxiBAS BT608E car battery tester applies future technology “Adaptive Conductance” that can identify low capacity batteries or batteries that are almost completely discharged and thereby reduce battery misdiagnosis. No need to charge and retest, improves battery testing efficiency and accuracy for technicians and DIYers.
Three highlights of AUTEL BT608E function:
1)Reduce Battery Misdiagnosis
2)Diagnose Low Capacity Batteries
3)Reduce Charge & Retest for Discharged Batteries
State-Of-The-Art Auto Battery Test:
Autel BT608E car load tester is designed to test 6V/12V Flooded, AGM, AGM Spiral, EFB and GEL batteries with CCA(100 to 3000 CCA), CA, SAE, EN, IEC, DIN, JIS and MCA standards. BT608 can test the battery state of health, offers illustration instruction guides for battery positioning and testing.
State of Charge: The amount of energy stored in the battery relative to its capacity.
Voltage: The difference in electric potential between the positive and the negative terminals of a battery.
Measure Capacity: Battery energy storage capacity measured in Cold Crank Amps.
Cranking Charging System Test/In-Vehicle Test&Out-Vehicle Test
BT608E Battery Tester can test battery and also 12- and 24-volt Cranking/Charging Systems( starter and alternator).
In-Vehicle Test:Cranking Voltage,Cranking Amps,Engine cranking speed before start
Out-Vehicle Test:BT608E can test the health of a battery when it’s not installed in the vehicle, just input the correct battery specifications based on the information printed on the battery’s label, verify battery type, battery standard and battery capacity.
Even when a battery is in a poor state of charge, it can accurately test its potential for stored energy without necessitating a recharge prior to test. This can expedite diagnosis and more quickly achieve the sales of a replacement unit.
One Touch Battery Replacement/Registration with Illustration Guides:
BT608E can perform battery registration/replacement at a single touch of the screen. It offers illustration guides to show the whole battery replacement process.
After registration of new battery, it can perform vehicle systems initialization to reset the components.
Re-Initialize Vehicle Systems to Make Them Work Properly Again:
After battery replacement/registration, some vehicle systems may not work properly after a complete power loss. BT608 batter test scanner comes with "Electric Appliance Reset" feature to enable mechanics and DIYers to re-initialize or restore learnt values critical to both safety and convenience related vehicle systems like sunroof reset, lane-departure warning system and Pre-Collision system and Emission Inspection and Maintenance program.
Autel BT608E Car Battery Capacity Tester with All Systems Diagnostics
Wireless All Systems Diagnosis
Coming with a wireless VCI, BT608E can work on 83+ American, European and Asian vehicle makes and models up to 2019, 2020 and some up to 2021 to access and scan all available systems wirelessly via BT to perform all systems diagnosis, including reading and clearing fault codes, viewing live data, and freeze frame data.
Combined Auto VIN and Auto Scan features, BT608E can quickly identify vehicle make, model and year and perform comprehensive scan on all available systems to perform efficient and accurate diagnosis.
Auto VIN Auto Scan Plate Scan
BT608E Auto Battery Test Scan Tool comes with Auto VIN, Auto Scan and Plate Scan features to acquire vehicle and battery specifications by simply scanning using the built-in 8MP HD camera.
Easy Customized Report Sharing via Built-In Thermal Printer
BT608E allows DIYers and technicians to print reports immediately after performing a test or later, all reports are saved in Data Manager.
- Built-in printer (kit includes 2 rolls of paper)
- WIFI printing via the Autel PC MaxiSuite desktop app
- E mail
- Customizeable: Report title, shop information, technician name
Built-In Multimeter Software&Lifetime Software Online Updates & Cloud-Based Apps
BT608E car battery load tester comes with built-in multimeter software which costs few hundred bucks itself.
Note: The leads for the multimeter is optional with separate purchase.
Autel BT608E Car Battery Capacity Tester comes with lifetime software online updates for new-coming features, continuously improved software performance and increased vehicle coverage.
BT608E Battery Test Scan Tool also features cloud-based apps like Remote Desk(Remote Assistance) and Data Manager for Data Logging with which auto technicians and DIYers can get best tech support from Autel engineers elite team.
Specifications:
Operating System：Android 9.0
Screen Display：5.5'' LCD touch screen with 720*1280 resolution
Storage：2 GB
Connectivity：Wi-Fi (802.11 a/b/g/n/ac)
USB 2.0 , Type C
BT5.0+EDR
Camera：8 Megapixel
Input Voltage：5 V DC
Working Current：< 450 mA at 7.7 V DC
Internal Battery：7.7 V, 3000 mAh
CCA Range：100 to 3000 A
Voltage Range：1.5 to 36 V
Working Temperature：0° to 50° C (32° to 122° F )
Storage Temperature：-10° to 60° C (14° to 140° F )
Dimension (L x W x H)：204 mm (8.03”) x 90 mm (3.54”) x 32 mm (1.25”)
Weight：510 g (1.12 lb.)
Package:
1*Main Unit
1*Maxivci V200 Series
1*Battery Clamp Cable
2*Paper Roll
1*Power Adpater
1*USB Cable
2*Battery Side Post Terminal TYPE T
2*Battery Side Post Terminal TYPE S
